Circle Vibration Screen Overview

Circular vibrating screen is named by the approximately circular movement of materials . It is widely used for grading and screening materials in the following fields: minerals, quarry, building materials, water conservancy and hydropower, transportation, chemical industry, smelting and so on.

Circle Vibration Screen Features

1.Reliable structure.

2.Strong exciting force.

3.High efficiency.

4.Easy to install and easy to operate.

5.Less maintenance

Circle Vibration Screen Working Principle

Circle Vibration Screen mainly consists of the eccentric block vibrator, screen box, motor, and supportive device.Through the flexible coupling, the motor drives the eccentric block of the vibrator rotate at high speed, generating the centrifugal force, and then causing the screen box do circular movement by the amplitude. After that, the materials on the slope screen surface will be cast continuously by the force generated from the screen box, then realizes the purpose of classifying.

Circular Motion: The circular vibrating screen operates using a circular motion, where the vibrating mechanism causes the screen surface to move in a circular path. This motion pattern allows the material to be evenly distributed on the screen surface and ensures efficient screening.

Screen Deck: The circular vibrating screen typically consists of one or more screen decks, each containing a mesh or perforated plate. These screen decks are arranged in layers, with the finer mesh or plates located closer to the feed end to facilitate the separation of finer particles.

Vibration Mechanism: The vibration mechanism of a circular vibrating screen usually involves an eccentric shaft with eccentric weights or unbalanced flywheels mounted at both ends. When the motor rotates the eccentric shaft, it generates a circular motion in the screen box, causing the material on the screen surface to move in a circular path.

Material Separation: As the material is fed onto the circular vibrating screen, the particles smaller than the screen openings pass through the mesh or perforations and are collected as undersize material. Larger particles remain on the screen surface and are discharged at the end of the screening process.

Adjustability: Operators can adjust various parameters of the circular vibrating screen, such as the amplitude and frequency of the vibration, to optimize the screening performance for different types of materials and particle sizes.

Screening Efficiency: Circular vibrating screens are known for their high screening efficiency, as the circular motion promotes even distribution of the material across the entire screen surface. This helps to prevent material buildup and blinding of the screen openings, resulting in improved screening capacity and efficiency.

Versatility: Circular vibrating screens are versatile and can be used for a wide range of applications, including screening of dry or wet materials, scalping ahead of crushers or grinding mills, dewatering, and classification of various particle sizes.

Low Maintenance: Circular vibrating screens typically have a simple design and are easy to maintain. They require minimal downtime for maintenance and are equipped with durable components to withstand the rigors of continuous operation in industrial environments.

Circle Vibration Screen Application

It is widely used for grading and screening materials in the following fields: minerals, quarry, building materials, water conservancy and hydropower, transportation, chemical industry, smelting and so on.
